Span: | 23'0"/ 7,01 m |
| Length: | 20'4"/ 6,22 m | |
| Height: | 5'5"/ 1,68 m | |
| Wing Area: | 110 sq ft/ 10,22 m2 | |
| Empty Weight: | 905 lbs/ 411 kg | |
| Gross Weight: | 1500 lbs/ 680 kg | |
| Wing Loading: | 13,64 lbs/sqft/ 67 kg/m2 | |
| Power Loading: | 9,4 lbs/hp/ 4,2 kg/PS | |
| Engine: | 160 PS (150-200PS) | |
| Fuel Capacity: | 32 gal/ 121 l | |
| Baggage: | 30 lbs/ 14 kg | |
| Performance solo: (Fixed pitch prop) | ||
| Top Speed: | 205 mph/ 178Kn/ 330 km/h | |
| Cruise 75% @ 8000 ft: | 193 mph/ 168Kn/ 310 km/h | |
| Cruise 55% @ 8000 ft: | 174 mph/ 151Kn/ 280 km/h | |
| Stall Speed: | 48 mph/ 42Kn/ 77 km/h | |
| Takeoff Distance: | 300 ft/ 91 m | |
| Landing Distance: | 300 ft/ 91 m | |
| Rate of Climb: | 2050 ft p. min/ 10,4 m p. sek | |
| Ceiling: | 24000 ft/ 8717 m | |
| Speed Ratio: | 4.2 : 1 | |
| Aerobatic Limits: | +6/-3 G | |
| Roll Rate: | 150 deg/second | |
| Fuel consumption: | Yes | |
